Add to Cart
Anti - climbing mesh has more rigid double vertical wire welding structure, which makes it difficult to cross. Anti climb fence is also known as "358 Fence" or "Prison Mesh". Anti-climb rigid mesh fencing has the advantages of anti-climbing, anti-cutting, anti-corrosion, and good viewing visibility. Combined with the fence top of razor barbed wire, security fence spikes, or tooth spikes, it becomes a ideal high-security fencing for high-end applications, such as, prisons, military and power facilities.
| Panels | Posts | ||||
| Fence | Panel Size | section | O/A Length | Total number of fixings | |
| Height (m) | Height/Width (mm) | mm | Inters- 1 Clamp bar | Corners- 2 Clamp bars | |
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 |
| 3.0 | 2997 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 |
| 3.3 | 3302 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 |
| 3.6 | 3607 x 2515 | 100x60x3mm | 4500 | 13 | 25 |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | 14 | 26 |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
| Width | 2m to 3m |
| Height | 1800mm, 2000mm, 2400mm, 3000mm, 4000mm, 5200mm |
| Hole Size | 3"×1/2", 75mm×13mm |
| Wire Dia. | 4mm(8 guage) |
| Weave Technique | Welded |
Others dimensions at your special need.
Good viewing visibility, it is a type of high security clear view fencing. Welded well at each intersection. Intrusion resistant, with extremely strong double vertical wire design. Small mesh aperture, anti-cut, anti-climb, finger-resistant and toe-resistant. Corrosion resistant with zinc aluminum alloy and PVC powder coating. Surface finish after welding, every weld-point are protected well. High strength with fully integrated with posts and anti-tamper fixings. Fence security toppings are optional. Easy for installation.
